Carriages and Carriage Parts - Rated by the tine carriage hoisting capability, there are four sizings of hook type tine carriages. The hook type tine carriages have been standardized.
The carriage bar spacing used for Class 1 is more or less thirteen inches and the Class 1 carriage is rated to carry cargo as much as 2000lbs. The Class 2 carriage is rated to hold cargo up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing for this capacity is 25 inches.
Pin mounted blades differ by the amount of offset between the tine and the fork eye. Some manufacturers will vary the carriages for pin type tines. Carriage capacity will be determined by the carriage pin size and by the fork size.
